Technical Specifications
SPECIFICATIONS
| SPECIFICATION | FT7001 |
|---|---|
| Connection | 1/4-inch MNPT |
| Port / Body Material | Brass |
| Housing Material | — |
| Dial Diameter (mm / in) | — |
| Max Flow (LPM / GPM) | 40 / 10.5 |
| Max Pressure (Bar / PSI) | 20 / 300 |
| Opening Temperature (°C / °F) | 60 / 140 |
| Weight (kg) | 0.02 |
| Box QTY | 10 |
Features
- Connection: 1/4-inch MNPT.
- Max Pressure (Bar / PSI): 20 / 300.
